Product Overview
This autoclave‑cured carbon fiber bulkhead acts as internal partition and load‑transfer structural part inside UAV fuselage. It replaces aluminum bulkhead to cut down overall airframe weight, transfers flight load evenly and improves fuselage rigidity against vibration. Custom cut‑outs and mounting bosses can be realized per drawing.
Key Features
Optimized lay‑up design for load transfer inside drone fuselage, improve overall structural rigidity.
Autoclave vacuum forming controls internal porosity, enhances anti‑fatigue performance under continuous flight vibration.
Lighter than aluminum counterpart, reduces fuselage dead weight and lifts available payload capacity.
Stable dimension under temperature fluctuation, avoids deformation that affects internal component assembly.
Support custom cut‑out, opening and pre‑embedded mounting fittings for assembly requirement.
Specifications
| Item | Parameter |
|---|---|
| Molding Process | Autoclave vacuum forming |
| Material | Carbon fiber prepreg |
| Outer Profile | Custom per drawing |
| Lay‑up configuration | Customized for load requirement |
| Cut‑out pattern | Custom |
| Embedded fittings | Confirm with supplier |
Applications
Internal load‑transfer bulkhead for VTOL fuselage
Multi‑rotor drone frame partition support panel
Light fixed‑wing aircraft inner compartment separator
Why Choose Us
We are direct manufacturer specialized in custom autoclave carbon composite parts for UAV and light aviation field. Our production facility owns full autoclave lines and precision CNC equipment, we provide legal export service for global aviation clients, capable of prototype trial as well as mass batch production.
Custom lay‑up matched to actual fuselage load‑transfer demand.
Strict porosity control during autoclave curing for stable batch performance.
One‑stop service including molding, cut‑out processing and embedded hardware.
Dimensional inspection before delivery to guarantee assembly tolerance.
Certification & Warranty
ISO9001 certificate available. Mechanical performance test reports Confirm with supplier. Warranty Confirm with supplier based on actual order.
Trade Terms
Service: OEM, ODM, custom manufacturing by drawing
MOQ: Confirm with supplier
Lead time: Confirm with supplier
Shipping: Negotiable
Export: Full set legal export documents
FAQ
Q1: What is this carbon fiber bulkhead used for? A1: It is internal load‑transfer partition component for UAV fuselage of VTOL and multi‑rotor drone.
Q2: Can it replace aluminum bulkhead for drone fuselage? A2: Yes, it achieves effective weight reduction while meeting fuselage load transfer requirement.
Q3: How to determine lay‑up scheme for my bulkhead? A3: Please provide drawing and fuselage load condition, we will recommend proper lay‑up solution.
Q4: What specifications are needed for a quotation? A4: 2D/3D drawing, load requirement and order quantity should be offered for accurate quote.
Q5: What is the MOQ and lead time? A5: MOQ and lead time Confirm with supplier subject to prototype or mass‑production.
Q6: Do you supply certificates or test reports? A6: ISO9001 certificate can be provided; partial mechanical test reports Confirm with supplier.
Q7: Can you make various cut‑outs and pre‑embed mounting parts? A7: Yes, custom cut‑out and embedded fittings can be processed according to your drawing.
