Detailed Description
Aluminum alloy airframes are the default choice for many UAV integrators-until they aren't. Field data from survey VTOL operators shows airframes exceeding 2.8kg suffer 22% shorter mission time and 15% higher motor temperature under continuous load. Worse, coastal deployments expose aluminum to salt spray, accelerating galvanic corrosion at fastener interfaces within 6–8 months.
Our solution: T700 unidirectional prepreg (UD) layup, autoclave cured at 180°C/7bar, resulting in void content ≤1.2% (ASTM D3171). Replacing 6061-T6 aluminum with this carbon plate yields a 45% mass reduction at equivalent flexural stiffness (tested to 850 GPa·mm⁴ section modulus). Surface Ra ≤0.8μm after CNC profiling eliminates delamination risk during routing-critical for thin-wall wing rib sections under ±6g maneuver loads.
Batch-to-batch fiber volume fraction is controlled at 62±2%, fully traceable via production lot records. Each shipment includes material certification and dimensional inspection report. For UAV and light fixed-wing applications requiring legal export compliance, we handle documentation including MSDS and UN transport classification.
Specification
|
Parameter |
Value |
|---|---|
|
Material |
T700 UD prepreg / 3K twill surface option |
|
Process |
Autoclave cure, 180°C / 7bar |
|
Thickness range |
0.5mm – 12mm |
|
Panel max size |
1500×1000mm |
|
Void content |
≤1.2% (ASTM D3171) |
|
Fiber volume fraction |
62±2% |
|
Flatness tolerance |
±0.1mm / 500mm |
|
Operating temp |
-55°C to +120°C |
|
Export docs |
MSDS, CO, Material cert, Test report |
Custom FAQ
Q: Can this plate be used for light aircraft wing ribs under EASA CS-23 structural loads?
A: Yes, the T700 UD layup meets CS-23 ultimate load factors when designed per our FEA layup schedule. We provide layup documentation and mechanical test data to support your airworthiness submission.
Q: What CNC tolerances can you hold on 3mm thick plates?
A: Standard ±0.1mm; high-precision option ±0.05mm with anti-delamination tooling paths.
Q: Is legal export clearance supported for carbon fiber plates to EU and North America?
A: Yes. We prepare full export documentation including HS code classification (6815.99), material safety data, and dual-use compliance screening.
