Big drones need big frames. And big frames need to be stiff, light, and reliable - because when you're carrying a gimbal, a Li-Ion pack, and a full-size action cam, there's no room for a frame that flexes mid-flight.
10-Inch Frame Specs:
Wheelbase: 480mm
Bare frame weight: 1400g
Rated payload: 1500g
Max takeoff weight: 3000g
Arm thickness: 6mm (standard), 8mm (heavy duty)
Plate material: 3K twill T700, 65% fiber volume
Stack: 30.5×30.5 main, 20×20 secondary
Battery bay: fits 6S–12S Li-Ion/LiPo, max 50×150×60mm
Landing gear: carbon tube skids, 150mm ground clearance
Also Available:
5" (230mm, 450g, 420km/h) for speed builds
7" (300mm, 650g, 350km/h) for balanced performance
✅ Export & Compliance:
Declared as "Carbon Fiber UAV Chassis / Heavy-Lift Drone Frame"
Frame-only = not a complete aircraft, lower regulatory threshold in most jurisdictions
Full docs: CI, PL, CO, material test report, MSDS
We do not ship complete armed/weaponized systems
Buyer responsible for local UAV registration and electronics compliance
Shipping: DHL for samples; air freight for 5–20 sets; sea freight for 20+ sets
Export experience: US, EU, UK, AU, UAE, SG, ZA, BR - cleared successfully
Send your payload requirements (camera + battery + accessories). We recommend size and ship a sample frame.
