1. Core Advantages - Three Decisions That Make a Good Frame Plate
Fiber grade matched to the mission. T300 for 3–5" FPV racers, T700 for 7–10" long-range and cinematic, T800 for industrial and heavy-lift. One plate grade across the range means either overpaying or breaking early.
Thickness per part, not per plate. Top and bottom plates at 2.5 mm; arms at 5 mm - load-path logic. Thickening the whole panel adds dead weight; thinning the arms loses crash resistance.
Holes that actually line up. CNC tolerance ±0.1 mm - motor mount and standoff holes match across top plate, bottom plate and arms. Misaligned holes are the #1 assembly complaint.
carbonfactorys.comCansda
2. Parameter Table (Typical Values, by Frame Class)
| Frame class | Fiber grade | Top/bottom plate | Arms | Reference frame weight |
|---|---|---|---|---|
| 3–5" FPV racer | T300 3K twill | 2.0 – 2.5 mm | 4 – 5 mm | ~100 – 120 g |
| 7" long-range / cinematic | T700 3K twill | 2.5 mm | 5 – 6 mm | ~130 – 160 g |
| 10"+ industrial / heavy-lift | T800 | 3.0 – 5.0 mm | 6 – 10 mm |
| Build parameter | Typical value |
|---|---|
| Weave | 3K twill / plain |
| Surface | Glossy or matte |
| CNC tolerance | ±0.1 mm (critical interfaces ±0.05 mm) |
| Accepted drawings | DWG / DXF / STEP / PDF |
| MOQ | 1 pc sample order accepted |
Typical industry values; locked from your design and approved sample.
3. Customization - DFM Before Production
We flag manufacturability - hole spacing, edge radius, arm relief, where thin plates will delaminate.
Approve the sample - we lock machining parameters; every reorder matches it.
Batch or private label - your logo, your packaging, your kit.
4. Company Advantages - Built Around Export Orders
Our export workflow is designed for overseas drone brands and kit makers:
Start with a sample. 1 pc sample order; color (gloss/matte) and thickness approved before bulk.
Batch consistency. Same fixtures, same QC after sample sign-off - reorders are repeat orders, not new projects.
Flexible shipping. DHL/FedEx for samples and small kits; sea freight for bulk.
5. FAQ
Q: Which fiber grade should my frame use? By mission: T300 for racing, T700 for long-range, T800 for heavy industrial. Tell us your target weight and load; we recommend.
Q: What tolerance do you hold? ±0.1 mm typical; critical interfaces ±0.05 mm. Standoff holes and motor mounts are checked per batch.
Q: Glossy or matte? Both. Glossy shows the weave; matte hides fingerprints. Cut parts usually deburred on both.
Q: What's the minimum order? Sample from 1 pc; bulk pricing tiers after.
