Detailed Description
Survey VTOL with 6061-T6 aluminum spars show >100mm wingtip deflection at 8kg MTOW-reducing L/D by 12–14% and cutting survey area per sortie. Thermal softening worsens this in midday sun.
Feature: T800 IM carbon prepreg, [0/90/±45]ns, autoclave 7bar.
Advantage: IM modulus 294GPa, plate flex mod ≈170GPa, void ≤1.0%, FVF 63±1.5%.
Benefit: 48% lighter than Al spar; deflection drops from 105mm→16mm under same load (3-pt bend verification); fatigue >10⁶ cycles @60% UTS, no delamination; enables 18–22% longer flight lines per battery.
CNC high-speed compression cut protects thin edges. Batch records: prepreg lot → cure cycle → C-scan. Export docs included.
Specification
|
Parameter |
Value |
|---|---|
|
Fiber |
carbon fiber prepreg |
|
Layup |
[0/90/±45]ns sym. |
|
Process |
Autoclave prepreg |
|
Size |
up to 2000×1000mm |
|
Thickness |
1.0–15mm |
|
Flex mod. |
≈170GPa |
|
Void |
≤1.0% |
|
Fatigue |
>10⁶ cyc @60% UTS |
|
Export |
Legal export full docs |
Certifications
FAQ
Q: Direct bolt-in for aluminum spar?
A: Bearing stress check required-we supply ASTM D953 allowables. Reinforce with local inserts if needed.
Q: Deflection comparison data available?
A: Yes, 3-pt bend test report per batch + FEA comparison on request.
Q: RF antenna proximity concern?
A: Carbon is conductive-keep >50mm or use RF-transparent fairing inserts.
Q: Traceability?
A: Lot ID links fiber mill cert → layup → cure log → dim inspection.
Q: Export to Europe?
A: Full pack: invoice HS 6815.99, MSDS, CO, material cert, dual-use decl.
