Aluminum central frame plates for multi-rotor drones add substantial dead weight, shortening flight duration. Thin aluminum also undergoes permanent bending deformation under landing impact and transmits strong motor vibration to onboard electronics. Our 3K twill hot press carbon fiber plate solves these structural drawbacks via custom prepreg stacking design.
We adopt 3K twill woven carbon prepreg manufactured by hot pressing with precisely controlled heating and pressure curve. The fiber stacking sequence can be customized according to the stress distribution of drone central frame, with void content kept ≤1.0%. Compared to 6061 aluminum plate of equal bending stiffness, our carbon plate reduces weight by 55%. It maintains stable dimension under continuous cyclic vibration and resists permanent deformation after repeated landings. CNC operations including grooving, drilling and contour cutting can be processed directly without obvious interlayer delamination.
This panel is widely used for multi-rotor drone central frame, motor mount base and battery support plate. It keeps stable mechanical performance within -35℃~115℃, retaining over 92% strength after 500h damp heat aging test.
Our Factory & Export Advantage
We are an integrated carbon composite source factory equipped with hot press machines and 4m×2m large-format CNC engraving equipment, certified ISO9001. All carbon prepreg raw materials have complete COA certificates for each batch. QR traceability code records the full curing curve of every batch. Our composite engineers help customers optimize layup to balance rigidity and weight. We supply full one-stop service: molding, CNC precision machining and surface finishing. Shock-proof export packaging protects panels in sea and air transport. Samples ready in 3-5 working days, tiered pricing for bulk orders. 18-month warranty for manufacturing defects, technical reply within 4 hours for overseas inquiries.
Specification
| Item | Parameter |
|---|---|
| Carbon Fabric | 3K Twill Weave Prepreg |
| Molding Process | Hot Press Molding |
| Void Content | ≤1.0% |
| Operating Temperature | -35℃ ~115℃ |
| Dimensional Tolerance | ±0.08mm |
| Surface Finish | Glossy / Matte carbon texture |
FAQ
Q1: Can we adjust fiber layup to suppress frame vibration?
A1: Yes, our engineers tune 0°/90°/±45° fiber stacking based on FEA analysis to reduce vibration transmission.
Q2: Does CNC grooving cause delamination?
A2: Strict hot press curing ensures strong interlayer bonding, greatly lowering delamination risk during CNC processing.
