1. Core Advantages - What the Mast Actually Does
It lifts the patch off the carbon shield. Carbon plate under the antenna detunes it; a mast holds the patch 30 mm up or more, with open sky above.
It separates the antenna from the noise source. ESC switching and motor wires radiate broadband noise. Moving the antenna up and out is the single most effective fix.
It adds grams, not weight. Roll-wrapped carbon tube is stiff enough not to flutter in flight, light enough not to care about on the scale.
Unmanned Techarkelectron.gitbook.io
2. Parameter Table (Typical Values, by Mast Height)
| Class | Height above deck | OD | Typical use |
|---|---|---|---|
| Low | 30 – 50 mm | 6 – 8 mm | FPV / small quad |
| Standard | 50 – 100 mm | 8 – 10 mm | Mapping / inspection |
| Tall | 100 mm+ | 10 – 12 mm | Heavy / RTK |
| Build parameter | Typical value |
|---|---|
| Material | Roll-wrapped carbon tube |
| Base mount | Hole spacing to your frame |
| Top connector | For your GPS patch / SMA |
| Surface | Glossy / matte |
| MOQ | Stock sizes from small qty |
Typical industry values; height and base locked from your layout.
3. Customization - Match Your Frame
Length cut to your required height.
Base hole spacing drilled to your top plate.
Top fitting for your antenna (SMA / patch mount).
Folding option for transport, on request.
4. Company Advantages - Export Supplier
Stock + custom. Standard sizes ship fast; custom base cut to order.
Flexible shipping. Express for samples, sea freight for bulk.
5. FAQ
Q: How high should the mast be? Aim for 30 mm+ above the carbon deck; taller for noisier power setups.
Q: Does the tube itself block the antenna? The patch faces up; a non-conductive standoff between patch and carbon deck is the recommended detail.
Q: Can you match my frame's base holes? Send the hole spacing; we drill to match.
Q: Will it flutter in flight? Roll-wrapped carbon is stiff for its weight; sized to the height you specify.
